| TECHANICAL DETAIL |
| SHEET SIZE |
600 MM / 800 MM |
| BRUSH SIZE |
DIA. 150 X 650 MM / 850 LG. MM |
| NO. OF BRUSHING HEAD |
1 |
| SHEET MOVING |
ROLLER TYPE |
| PROCESS |
DRY ONLY |
| FINISH |
MATT |
| SHEET THICKNESS |
0.75 TO 3 MM |
| BRUSH PRESSURE |
MOTORISED |
| BRUSH OSCILATION |
10 + 10 MM |
| WEIGHT |
1 TON APPROX |
| REQUIRED LABOUR |
2 |
| MACHINE POWER SUPPLY |
3 PHASE |
| BRUSH MOTOR |
5 HP BBL / HINDUSTAN MAKE |
| BRUSH UP-DOWN MOTOR |
0.5 HP FENNER / HINDUSTAN MAKE |
| BRUSH OSCILLATION MOTOR |
1 HP BONFIGLIOLI / HINDUSTAN MAKE |
| CONVEYOR GEAR MOTOR |
1 HP BONFIGLIOLI / HINDUSTAN MAKE |
NOTE: WE MAKE CUSTOM MACHINE AS PER CLIENT REQUIREMENT
