| TECHANICAL DETAIL |
| BRUSH POLISH |
BOTH SIDE |
| BRUSH SIZE |
DIA. 200 X 300 LG. |
| CONVEYOR TABLE |
BOTH SIDE 3M |
| NO. OF BRUSH |
2 TOP & 2 BOTTOM |
| PROCESS |
DRY ONLY |
| FINISH |
MATT / MIRROR |
| BUSBAR SIZE |
10 MM TO 300 MM WIDTH |
| BUSBAR THICKNESS |
2 MM TO 30 MM |
| THICKNESS ADJUST |
MANUALLY |
| BRUSH PRESSURE |
MOTORISED |
| BRUSH OSCILATION |
10 + 10 MM |
| PRODUCTION |
8 TO 10 TON / SHIFT |
| REQUIRED LABOUR |
2 + 1 |
| MACHINE POWER SUPPLY |
3 PHASE |
| MACHINE SIZE |
2500 X 1500 X 1200 MM |
| ROLLER CONVEYOR TABLE |
3 M + 3 M |
| MACHINE SIZE WITH CONVEYOR TABLE |
8500 X 1500 X 1200 MM |
| TOTAL MACHINE WEIGHT |
2 TON |
| BRUSH MOTOR |
5 H.P. BBL / HINDUSTAN |
| BRUSH UP-DOWN MOTOR |
0.5 H.P. FENNER + HINDUSTAN |
| CONVEYOR GEAR MOTOR |
1 H.P. BONFIGLIOLI + HINDUSTAN WITH VFD CONTROL |
| OSCILLATION GEAR MOTOR |
1 H.P. BONFIGLIOLI + HINDUSTAN |
NOTE: WE MAKE CUSTOM MACHINE AS PER CLIENT REQUIREMENT
